Welding polarity ccD visual inspection machine
The CCD scanning and detection machine is designed accordingto the battery module's battery cell placement requirements,and the scanning and detection have no errors, omissions, orother phenomena.Visually inspect the polarity of the batterycells to determine if the photographed images meet thestandards.
- Information
Summary
The CcD scanning and detection machine is designed accordingto the battery module's battery cell placement requirements,and the scanning and detection have no errors, omissions, orother phenomena.Visually inspect the polarity of the batterycells to determine if the photographed images meet thestandards.Independently developed software, PC highconfiguration hardware+self-developed board+motor+sensor,etc.Humanized foolproof, error proof system, automaticshutdown alarm for abnormalities, and system automaticteaching confirmation detection items.
Scope of application
CCD detection machine is suitable for detecting the front and back of battery cells
Technical Parameter
| Hostinput power supply | External dimensions | CCD field of view |
| AC220V 50-Hz | 950mm*800mm*1800mm | 300mmX320mm |
